Pipeline Booster Pump
TD portable pipeline booster pump is equipped with high-efficiency standard motor. Through hydraulic and structural optimization, it has the characteristics of high efficiency and energy saving, stable performance, low noise, no overload, large flow, wide high-efficiency area and beautiful appearance; The utility model has the advantages of compact structure and convenient installation and disassembly. The product is designed as a disassembly and assembly form that can be pulled out from the top, which can repair the pump without affecting the pipeline system; This product can replace the same type of foreign products.
Technical Data：
| No | Model | (kW) | Q(m³ /h) | 4 | 8 | 12.5 | 16 | 20 | 25 | 28 | 32 |
| 1 | TD40-16/2 | 1.1 | H(m) | 17.8 | 17.3 | 16 | 12.5 | ||||
| 2 | TD40-20/2 | 1.5 | 21.5 | 21.1 | 20 | 17.2 | |||||
| 3 | TD40-18/2 | 2.2 | 19.9 | 19.8 | 19.5 | 19 | 18 | 15.8 | |||
| 4 | TD40-25/2 | 3 | 27.7 | 27.5 | 27.1 | 26.4 | 25 | 22.5 | |||
| 5 | TD40-30/2 | 4 | 33.8 | 33.6 | 33.1 | 32.6 | 31.7 | 30 | 28.6 | 26.1 | |
| 6 | TD40-36/2 | 5.5 | 39 | 38.8 | 38.5 | 38.1 | 37.3 | 36 | 35 | 32.6 | |
| 7 | TD40-48/2 | 7.5 | 49.8 | 49.7 | 49.5 | 49.4 | 49 | 48 | 46.6 | 44.2 |
| No | Model | (kW) | Q(m³ /h) | 5 | 10 | 16 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 |
| 1 | TD50-12/2 | 1.1 | H(m) | 15.2 | 14.2 | 12 | 10 | |||||||
| 2 | TD50-15/2 | 1.5 | 18.9 | 18 | 16.5 | 15 | 12.6 | |||||||
| 3 | TD50-18/2 | 2.2 | 22.8 | 22.3 | 21 | 19.8 | 18 | 15 | ||||||
| 4 | TD50-24/2 | 3 | 26.2 | 26 | 25.5 | 25 | 24 | 22.3 | ||||||
| 5 | TD50-28/2 | 4 | 31.5 | 31.3 | 31 | 30.5 | 29.5 | 28 | 25.5 | |||||
| 6 | TD50-35/2 | 5.5 | 36.9 | 36.7 | 36.5 | 36.2 | 35.8 | 35 | 33.7 | 31.5 | ||||
| 7 | TD50-40/2 | 7.5 | 42.3 | 42.2 | 41.9 | 41.7 | 41.3 | 40.8 | 40 | 38.3 | 35 | |||
| 8 | TD50-50/2 | 11 | 53.5 | 53.4 | 53.1 | 52.9 | 52.5 | 51.9 | 51.1 | 50 | 48.4 | 45.8 | ||
| 9 | TD50-60/2 | 15 | 65.7 | 65.8 | 65.7 | 65.6 | 65.3 | 64.7 | 63.9 | 62.8 | 61.6 | 60 | 55.4 | |
| 10 | TD50-70/2 | 18.5 | 73.7 | 73.6 | 73.4 | 73.3 | 73.1 | 72.9 | 72.5 | 72 | 71.2 | 70 | 65.4 | |
| 11 | TD50-81/2 | 22 | 85.5 | 85.3 | 85 | 84.8 | 84.5 | 84 | 83.5 | 82.8 | 82.1 | 81 | 77.1 |
| No | Model | (kW) | Q(m³ /h) | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 |
| 1 | TD65-12/2 | 1.5 | H(m) | 14.2 | 13.1 | 11 | 7.2 | |||||
| 2 | TD65-15/2 | 2.2 | 17.9 | 17 | 15 | 10.7 | ||||||
| 3 | TD65-19/2 | 3 | 21.7 | 20.8 | 19 | 15.2 | ||||||
| 4 | TD65-22/2 | 4 | 25.1 | 24.7 | 23.9 | 22 | 17.5 | |||||
| 5 | TD65-30/2 | 5.5 | 32.4 | 32.1 | 31.5 | 30 | 26.1 | |||||
| 6 | TD65-34/2 | 7.5 | 38.6 | 38.2 | 37.6 | 36.4 | 34 | 29.6 | ||||
| 7 | TD65-40/2 | 11 | 43.4 | 42.9 | 42.3 | 41.4 | 40 | 37.6 | ||||
| 8 | TD65-50/2 | 15 | 53.6 | 53.3 | 52.7 | 51.6 | 50 | 47.3 | ||||
| 9 | TD65-60/2 | 18.5 | 63.1 | 63.2 | 63 | 62.3 | 60 | 58.8 | 54.8 | |||
| 10 | TD65-70/2 | 22 | 73.4 | 73.1 | 72.8 | 72.7 | 72.1 | 70 | 67.3 | 65.1 | 59.9 | |
| 11 | TD65-80/2 | 30 | 87 | 86.8 | 86.6 | 85.6 | 84.1 | 82.7 | 80 | 77.8 | 74.2 |
| No | Model | (kW) | Q(m³ /h) | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 |
| 1 | TD80-13/2 | 3 | H(m) | 16.1 | 15.8 | 15.2 | 14.3 | 13 | 10.9 | ||||
| 2 | TD80-18/2 | 4 | 21.1 | 20.8 | 20.2 | 19.2 | 18 | 16.2 | 13.2 | ||||
| 3 | TD80-22/2 | 5.5 | 24.4 | 24.1 | 23.7 | 23 | 22 | 20.5 | 18 | 14.3 | |||
| 4 | TD80-28/2 | 7.5 | 30.6 | 30.4 | 30 | 29.3 | 28 | 26.3 | 24 | 20.6 | |||
| 5 | TD80-33/2 | 7.5 | 35.2 | 34.7 | 34.4 | 34 | 33 | 32.7 | 30 | 28.4 | |||
| 6 | TD80-30/2 | 11 | 34.8 | 34.5 | 34.2 | 33.8 | 33.2 | 32.4 | 31.3 | 30 | 27.8 | 24.7 | |
| 7 | TD80-38/2 | 15 | 41.2 | 41.2 | 41.1 | 40.9 | 40.6 | 40.1 | 39.3 | 38 | 36 | 32.9 | |
| 8 | TD80-47/2 | 18.5 | 50.6 | 50.4 | 50 | 49.8 | 49.6 | 49.1 | 48.3 | 47 | 44.8 | 41.4 | |
| 9 | TD80-60/2 | 22 | 61.8 | 61.6 | 61.4 | 61.2 | 60.9 | 60.7 | 60.5 | 60 | 58.1 | 56.9 | |
| 10 | TD80-70/2 | 30 | 71.7 | 71.5 | 71.3 | 71.1 | 70.9 | 70.8 | 70.5 | 70 | 68.9 | 67.1 |
| No | Model | (kW) | Q(m³ /h) | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 | 120 | 130 | 145 | 160 |
| 1 | TD100-10/2 | 3 | H(m) | 14.6 | 14 | 13.2 | 12.3 | 11.1 | 10 | 8.7 | 6.8 | |||||||
| 2 | TD100-15/2 | 4 | 18.6 | 18.2 | 17.7 | 17.1 | 16.2 | 15 | 13.4 | 11 | ||||||||
| 3 | TD100-17/2 | 5.5 | 21.7 | 21.5 | 21.1 | 20.7 | 20 | 19.2 | 18.3 | 17 | 15.3 | 13 | 10.4 | |||||
| 4 | TD100-22/2 | 7.5 | 26.8 | 26.6 | 26.3 | 25.9 | 25.3 | 24.5 | 23.4 | 22 | 20.3 | 18.2 | 15.8 | |||||
| 5 | TD100-27/2 | 11 | 31.5 | 31.3 | 31.1 | 30.9 | 30.7 | 30.3 | 29.8 | 29.2 | 28.2 | 27 | 25.5 | 23.6 | 20.8 | |||
| 6 | TD100-33/2 | 15 | 37.1 | 37 | 36.8 | 36.6 | 36.2 | 35.8 | 35.3 | 34.7 | 33.9 | 33 | 31.7 | 30.1 | 27.9 | |||
| 7 | TD100-40/2 | 18.5 | 43.3 | 43.2 | 43.1 | 42.9 | 42.7 | 42.4 | 42.1 | 41.6 | 40.9 | 40 | 38.9 | 37.4 | 35.3 | |||
| 8 | TD100-48/2 | 22 | 51.2 | 51.1 | 51 | 50.8 | 50.6 | 50.3 | 49.9 | 49.4 | 48.8 | 48 | 46.9 | 45.3 | 43.2 | |||
| 9 | TD100-52/2 | 30 | 55.3 | 55.3 | 55.3 | 55.3 | 55.2 | 55.1 | 54.8 | 54.6 | 54.4 | 54.2 | 53.8 | 53.1 | 52 | 49 | 43.5 |
| No | Model | (kW) | Q(m³ /h) | 40 | 60 | 80 | 100 | 120 | 140 | 160 | 180 | 200 |
| 1 | TD125-11/4 | 5.5 | H(m) | 12.9 | 12.7 | 12.4 | 11.8 | 11 | 9.9 | 8 | ||
| 2 | TD125-14/4 | 7.5 | 16.2 | 15.9 | 15.5 | 14.9 | 14 | 12.8 | 11.2 | |||
| 3 | TD125-18/4 | 11 | 21.5 | 21.3 | 21 | 20.6 | 19.9 | 19.1 | 18 | 16.4 | 14.1 | |
| 4 | TD125-22/4 | 15 | 26.7 | 26.5 | 26.2 | 25.7 | 24.9 | 23.7 | 22 | 19.8 | 16.7 | |
| 5 | TD125-28/4 | 18.5 | 30.9 | 30.8 | 30.7 | 30.5 | 30.1 | 29.3 | 28 | 25.8 | 22.2 | |
| 6 | TD125-32/4 | 22 | 34.6 | 34.6 | 34.5 | 34.4 | 34 | 33.3 | 32 | 30.2 | 27.3 | |
| 7 | TD125-40/4 | 30 | 43.9 | 43.6 | 43.3 | 42.9 | 42.2 | 41.3 | 40 | 38 | 35.4 | |
| 8 | TD125-48/4 | 37 | 51.5 | 51.3 | 51 | 50.5 | 49.9 | 49.1 | 48 | 46.4 | 44.2 |
| No | Model | (kW) | Q(m³ /h) | 50 | 80 | 110 | 140 | 170 | 200 | 220 | 240 |
| 1 | TD150-10/4 | 7.5 | H(m) | 13.53 | 13.29 | 12.36 | 11.82 | 10.33 | 10 | 8.93 | 7.16 |
| 2 | TD150-12.5/4 | 11 | 14.6 | 14.5 | 14.4 | 14.2 | 13.7 | 12.5 | 11.1 | 9.2 | |
| 3 | TD150-17/4 | 15 | 18.8 | 18.8 | 18.7 | 18.5 | 18 | 17 | 16.1 | 15 | |
| 4 | TD150-21/4 | 18.5 | 23.3 | 23.1 | 22.9 | 22.6 | 22 | 21 | 19.8 | 17.9 | |
| 5 | TD150-25/4 | 22 | 28 | 28 | 27.8 | 27.3 | 26.5 | 25 | 23.5 | 21.3 | |
| 6 | TD150-33/4 | 30 | 35.5 | 35.4 | 35.2 | 34.8 | 34.2 | 33 | 31.5 | 29.6 | |
| 7 | TD150-40/4 | 37 | 43.1 | 43 | 42.8 | 42.4 | 41.6 | 40 | 38.4 | 36.2 | |
| 8 | TD150-50/4 | 45 | 52.4 | 52.2 | 52 | 51.7 | 51.1 | 50 | 48.7 | 46.7 |
| No | Model | (kW) | Q(m ³ /h) | 160 | 200 | 240 | 280 | 320 | 360 | 400 | 440 | 480 |
| 1 | TD200-12.5/4 | 22 | H(m) | 17.2 | 16.9 | 16.5 | 15.9 | 15.1 | 14 | 12.5 | 10.7 | 8 |
| 2 | TD200-20/4 | 30 | 24.6 | 24.4 | 24 | 23.6 | 22.8 | 21.7 | 20 | 17.5 | 14.2 | |
| 3 | TD200-23/4 | 37 | 28.1 | 27.8 | 27.4 | 26.8 | 25.9 | 24.8 | 23 | 20.9 | 18.2 | |
| 4 | TD200-27/4 | 45 | 32.1 | 31.7 | 30.2 | 30.5 | 29.6 | 28.4 | 27 | 24.9 | 22.5 | |
| 5 | TD200-32/4 | 55 | 37.5 | 37.1 | 36.5 | 35.7 | 34.7 | 33.3 | 32 | 29.9 | 27.7 | |
| 6 | TD200-43/4 | 75 | 47 | 46.7 | 46.4 | 45.9 | 45.3 | 44.4 | 43 | 41.1 | 38.6 | |
| 7 | TD200-50/4 | 90 | 52.9 | 52.8 | 52.6 | 52.2 | 51.7 | 51 | 50 | 48.3 | 45.5 |
| No | Model | (kW) | Q(m'/h) | 90 | 120 | 150 | 180 | 210 | 240 | 270 | 300 | 330 | 360 |
| 1 | TD200-16/4 | 18.5 | H(m) | 19.6 | 19.4 | 19.3 | 18.9 | 18.6 | 17.9 | 16.8 | 16 | 14.9 | 13.8 |
| 2 | TD200-19/4 | 22 | 22.5 | 22.4 | 22.1 | 21.6 | 20.7 | 20.4 | 19.8 | 19 | 17.2 | 16.1 | |
| 3 | TD200-24/4 | 30 | 26.1 | 26 | 25.8 | 25.7 | 25.4 | 25.1 | 24.6 | 24 | 23.1 | 21.9 | |
| 4 | TD200-31/4 | 37 | 34.1 | 33.7 | 33.4 | 33.3 | 33.2 | 33 | 32.1 | 31 | 29.3 | 27.4 | |
| 5 | TD200-36/4 | 45 | 38.4 | 38.2 | 38 | 37.9 | 37.7 | 37.1 | 36.4 | 36 | 33.8 | 32.2 | |
| 6 | TD200-47/4 | 55 | 48.7 | 48.5 | 48.4 | 48.2 | 48.1 | 47.9 | 47.7 | 47 | 44.1 | 42.4 | |
| 7 | TD200-53/4 | 75 | 55.7 | 55.7 | 55.7 | 55.5 | 55.3 | 54.8 | 54 | 53 | 51.6 | 50 |
| No | Model | (kW) | Q(m³ /h) | 240 | 300 | 360 | 420 | 480 | 540 | 600 | 630 | 660 | 720 | 750 |
| 1 | TD250-12.5/4 | 30 | H(m) | 18.4 | 17.9 | 17.2 | 16.4 | 15.5 | 14.5 | 13.2 | 12.5 | 11.8 | 9.9 | 8.7 |
| 2 | TD250-14/4 | 37 | 20 | 19.5 | 18.9 | 18.2 | 17.5 | 16.6 | 15.6 | 14 | 13.4 | 12.6 | 11.6 | |
| 3 | TD250-17/4 | 45 | 21.8 | 21.3 | 20.8 | 20.1 | 19.4 | 18.6 | 17.6 | 17 | 16.3 | 14.4 | 13.4 | |
| 4 | TD250-20/4 | 55 | 24.5 | 24.1 | 23.7 | 23.1 | 22.4 | 21.5 | 20.5 | 20 | 19.3 | 17.6 | 16.5 | |
| 5 | TD250-26/4 | 75 | 31.7 | 31.1 | 30.6 | 29.9 | 29.1 | 28.2 | 26.8 | 26 | 25.2 | 23.1 | 21.9 | |
| 6 | TD250-32/4 | 90 | 36.7 | 36.3 | 35.7 | 35.1 | 34.3 | 33.5 | 32.6 | 32 | 31.3 | 29.5 | 28.4 | |
| 7 | TD250-40/4 | 110 | 46 | 45.5 | 44.9 | 44.2 | 43.4 | 42.3 | 40.8 | 40 | 39.1 | 36.8 | 35.5 | |
| 8 | TD250-50/4 | 132 | 55.6 | 55.2 | 54.6 | 53.9 | 53.2 | 52.3 | 50.9 | 50 | 49 | 46.7 | 45.4 |
Remarks:
For examples
model: TD40-16/2, The number 2 represents a speed of 2900r/min.
model: TD125-11/4, The number 4 represents a speed of 1480r/min
Construction Characteristics
Diameter range: DN40-DN250
Flow range: 20m³/h ~ 630m ³/ h
Lift range: 10M ~ 81m
Power range: 1.5kw ~ 132kw
Power requirements: 3x380V 50Hz
Speed: 2900r / min 1480r / min
Medium temperature: 0 ~ 120 ℃
Ambient temperature: ≤ 40 ℃
Material:
1.set screw : carbon steel
2. pump shaft : 20Cr13
3. air screw assembly : 304
4. connection (pump cover) : HT200
5. mechanical seal : graphite, silicon carbide
6. impeller :HT200 / stainless steel
7. "O" ring :fluororubber / nitrile rubber
8. lock nut :carbon steel (nickel plated)
9. pump body: HT200
10. drain plug : stainless steel
11. outer hexagon nut : carbon steel (nickel plated)
12. outer hexagon bolt : carbon steel (nickel plated)
13. water injection blocking : stainless steel
Advantages
1. High-quality materials and mature manufacturing processes guarantee a longer service life.
2. 100% copper wire, cold-rolled silicon steel sheet .
3. It is more economical and more environmentally friendly.
4. It is easier and more widely used than any other dynamoelectric driven pumps.
5. High technique products adopting MPPT and DSP chip technique.
6.Low voltage make creatures and humans are absolutely safe
