Stainless Steel Well Pump Body

1.Made of all stainless steel. Impeller blades and deflector blades are all welded by laser.
2. Design of heavy duty water outlet chamber of check valve. Durable and easy to install.
3.Impeller The deflector operates under heavy load and is durable to ensure the best performance.
4. The stainless steel round hole filter screen cover effectively prevents sand and stone particles or other foreign matters from entering.
5. The copper graphite bearing of the imported deflector increases the stability of operation.

Send Inquiry

Technical Data

Model	Size (mm)			Power		Performance parameter
3-phase380V- 415V≈50HZ						m'/h
						m'/h	0	10	15	17	20	25
	A	B	rpm	KW	Hp	L/min	0	166	250	283	333	416
6SP17-3	242°/3*	145	2850	2.2	3	Head (m)	33	29	26	25	21	13
6SP17-5				3	4		55	49	44	41	35	21
6SP17-7				4	5.5		77	68	62	57	49	30
6SP17-9				5.5	7.5		99	88	79	74	63	38
6SP17-12				7.5	10		132	117	105	99	84	51
6SP17-15				9.2	12.5		165	146	131	124	105	64
6SP17-18				11	15		198	175	157	148	126	76
6SP17-21				13	17.5		231	205	184	173	147	89
6SP17-24				15	20		264	234	210	198	168	102
6SP17-30				18.5	25		330	292	262	247	210	127
6SP17-36				22	30		396	351	315	297	252	153
6SP17-43				26	35		473	419	376	355	301	183

Model	尺寸 (mm)			Power		Performance parameter
3-phase380V- 415V≈50HZ						m'/h
						m²/h	0	20	25	30	35	40
	A	B	rpm	KW	Hp	L/min	0	333	416	500	583	666
6SP30-5	3"	145	2850	5.5	7.5	Head (m)	66	53	47	39	30	18
6SP30-7				7.5	10		92	74	66	55	42	25
6SP30-9				9.2	12.5		118	95	85	71	54	32
6SP30-12				11	15		157	126	113	94	72	42
6SP30-14				13	17.5		184	148	132	110	84	50
6SP30-16				15	20		210	169	151	126	96	57
6SP30-19				18.5	25		249	201	179	150	114	68
6SP30-23				22	30		302	243	217	181	138	82
6SP30-28				26	35		367	296	264	221	168	100

Model	尺寸 (mm)			Power		Performance parameter
3-phase380V- 415V≈50HZ						m'/h
						m³/h	0	35	40	46	50	55
	A	B	rpm	KW	Hp	L/min	0	583	666	766	833	916
6SP46-4	3'/4'	152	2850	7.5	10	Head (m)	53	40	38	35	32	28
6SP46-5				7.5	10		66	50	48	44	40	35
6SP46-6				9.2	12.5		79	60	58	53	48	42
6SP46-7				11	15		92	70	67	62	56	49
6SP46-8				13	17.5		106	80	77	70	64	56
6SP46-10				15	20		132	100	96	88	80	70
6SP46-12				18.5	25		158	120	115	106	96	84
6SP46-14				22	30		185		134	123	112	98
6SP46-16				26	35		211	160	154	141	128	112
6SP46-18				30	40		238	180	173	158	144	126

Model	尺寸 (mm)			Power		Performance parameter
3-phase380V- 415V≈50HZ						m'/h
						m'/h	0	40	45	50	55	60
	A	B	rpm	KW	Hp	L/min	0	583	666	766	833	916
6SP60-4	3'/4°	152	2850	7.5	10	Head (m)	56	40	39	36	34	31
6SP60-5				9.2	10.5		70	51	48	45	42	39
6SP60-6				11	15		84	61	57	54	50	46
6SP60-8				15	20		112	82	77	72	67	62
6SP60-9				18.5	25		126	93	87	81	75	70
6SP60-10				18.5	25		140	103	96	90	84	78
6SP60-11				22	30		154	116	108	100	93	86
6SP60-12				22	30		168	124	112	110	102	94
6SP60-13				26	35		182	136	127	118	110	102
6SP60-14				26	35		196	146	137	128	119	110
6SP60-15				26	35		210	155	145	135	126	117
6SP60-16				30	40		224	168	156	145	135	125

Advantages of Stainless Steel Well Pump body
1. A longer service life is ensured by superior materials and sophisticated manufacturing techniques.
2. Cold-rolled silicon steel sheet and 100% copper wire.
3. It is more cost-effective and ecologically sustainable.
4. Compared to other dynamoelectric-driven pumps, it is simpler and more popular.
5. High-tech products that use DSP chip and MPPT techniques.
6. Low voltage ensures complete safety for both humans and animals.

Application Field of Stainless Steel Well Pump body
1. Deep well drinking water extraction;
2. Water for farmland irrigation and livestock;
3. Municipal and industrial water supply, liquid pressurization, mine drainage and other fields.
