Solar Swimming Pool Circulation Pump

Solar swimming pool circulation Pump(SSPC)

This product is based on the principle of solar power generation,mainly used for domestic and public swimming pools,plays a role in water circulation, water oxygen supply, and water filtration.

Security：It is all-round automatic protected by the controller , Avoid burning, overload, motor disconnection, etc.

Efficient：Compared to traditional water pumps , it has higher motor efficiency .

Economical and environmentally friendly：Saving electricity and human resources. Particularly useful in regions where electricity is lacking or human resources are expensive.

High technique products adopting  MPPT and DSP chip technique.

Technical Data

Construction Characteristics

1. Max.liquid temperature:+35℃

2. Max.suction：3.5m

3. Bearing:C＆U/NSK

Advantages

1.Low operating voltage and high safety.

2.Energy-saving and environment-protected green products , electricity saved after two years value back to pump cost.

3.Advanced brushless DC motor.

4.It is easier and more widely used than any other dynamoelectric driven pumps.

5.Saving human resources ,no need for personnel to take care of it,no need use diesel oil ,no need to use electrified wire netting.

6.Low voltage make creatures and humans are absolutely safe.

Application Field

It is used in small domestic or public swimming pools for pumping, cleaning, filtering, changing water, it is Suitable for large domestic and public artificial fountains, and hotel fountains.

Package Details

Standard Carton/ Fumigation-free wooden box

FAQ

1.What about the method of delivery?

By air on DHL/TNT/EMS,Container loading by FOB NingBo or ShangHai port.

2.Are you a manufacturer, trading company or a third party?

Manufacturer. We have been manufacturing water pump for 12 years.

3.How long is the delivery time of your product?

Normal 10-15 days.

4.What after-sales service can you get after buying your product?

Non-human issues are replaced within three years, including the controller part and the water pump part

5.Where is your factory located?

Our Marketing Center：Room 3110/3111,Intime City,Jiaojiang District,Taizhou City,Zhejiang Province,China.

Two Manufacturing Base:

a.Zhejiang base: Daxi Town,Wenling County,Taizhou City,Zhejiang Province,China.

b.Jiangxi base :Dingshan Penghuwan Industrial Zone,Pengze Town,Jiujiang City,Jiangxi Province,China.

Market in present

SSPC is a mature and efficient product, major customers are from Zimbabwe,Australia,UAE,Ukraine,Portugal,South Africa,Zambia,Tajikistan, Myanmar, etc.

After-sale service

Three-year warranty：Non-human issues are replaced within three years, including the controller part and the water pump part.

Model Select

A.The power of solar panel = power of pump ×1.3   ,The voltage of solar panel = the voltage of pump

The controller should be matched

B.Select the batteries according to the following formulas:

The use hour of battery = The battery capacity ÷(the machine power÷the battery voltage)×0.6 For example,the machine power is 200W, the battery capacity is 100AH,the voltage is 12V,and the battery is fully charged,then the use hour is:100÷(200÷12)×0.6=3.6hours

C.The battery capacity=

the use hour ÷0.6×(the machine power÷the battery voltage) For example,the machine power is 200W,the battery voltage is 12V,and the battery need to be used for 3.6hours,then the battery capacity is:3.6÷0.6×(200÷12)=100AH
